Profile
A21-XHD
Bow Locker
Heavy Duty Bow Towing Post
Large Square Transom Alum. Reinforced Base
Extra Heavy Duty Stringers and "V"Hull
Non-skid (CSM) Fabric on Tube
Integrated Aluminum Fuel Tank
Pressure Relief Valves
Ultra High Quality Welding
Bow U bolt and lateral towing eyes
Double Solid Rubrail
Heavy Duty "Aluminum" Keel Protector
1670 D-Tex ORCA (CSM) Coated Fabric
Sunbrella Fabric Boat Cover Available
Reinforced Alum. Lifting Eyes with SS Rings
Internal Aluminum Plate with Security Lip
Reinforced (CSM) Fabric Handles
Non-skid Rubber Floor
Reinforced Alum. Transom Towing Eyes w/ SS Rings
Reinforced Alum. Transom Tie Downs w/ SS Rings
Hydraulic Steering System and SS Wheel
Custom Colors & Consoles Upon Request
Overall Length
21' / 6.4m
Overall Beam
9'1" / 2.77
Inside Length
16'5" / 5m
Number of Chambers
6
Inside Beam
4'6" / 1.37m
Tube Diameter
22" / 0.56m
Person Capacity
17
Weight
1580 lbs / 717kg
Recommended HP
150hp / 111.9kw
Maximum HP
200hp / 149kw
Shaft length - Single Engine Installation
25" / 63.5cm
Shaft length - Twin Engine Installation
20" / 50.8cm
Fuel Built-In Tanks
51 gal / 193 lt - EPA compliant fuel tanks, 7% reduction approx.
RDC Design Category
C
Deadrise
23°
| Profile A21-XHD | Profile A24-XHD | |
|---|---|---|
| Overall Length | 21' / 6.4m | 24'8" / 7.52m |
| Overall Beam | 9'1" / 2.77 | 9'2" / 2.80m |
| Inside Length | 16'5" / 5m | 19'9" / 6.02m |
| Number of Chambers | 6 | 6 |
| Inside Beam | 4'6" / 1.37m | 4'8" / 1.42m |
| Tube Diameter | 22" / 0.56m | 24" / 0.61m |
| Person Capacity | 17 | 20 |
| Weight | 1580 lbs / 717kg | 1758 lbs / 799kg |
| Recommended HP | 150hp / 111.9kw | 150 hp / 111.9 kw |
| Maximum HP | 200hp / 149kw | 250 hp / 186.5kw |
| Shaft length - Single Engine Installation | 25" / 63.5cm | 25" / 63.5cm |
| Shaft length - Twin Engine Installation | 20" / 50.8cm | 20" / 50.8cm |
| Fuel Built-In Tanks | 51 gal / 193 lt - EPA compliant fuel tanks, 7% reduction approx. | 65 gal / 246 lt - EPA compliant fuel tanks, 7% reduction approx. |
| RDC Design Category | C | C |
| Deadrise | 23° | 23° |
Marine Grade Aluminum Hulls
Hydraulic Steering System
Bow Locker
Leaning Bolster
Bow Towing Post
Aluminum Console with Plexiglass Windshield & Rail
Integrated Aluminum Fuel Tank
Standard Rigging From Factory
SS LED Navigation Light
All Around LED Anchor Light
Automatic Bilge Pump
Master Switch
Fuel/Water Separator & Canister
Fuel Sending Unit
Reinforced Aluminum Bow Eye
Reinforced Aluminum Tow Rings
Drain Scuppers
Pressure Relief Valves
Solid Double Rubrail
4 Aluminum Davit Lifting Points
Non-Skid Orca (CSM) Coated Fabric On Top of Tube
Heavy Duty Non-Skid Rubber Floor Panels
4 Layer Reinforced Seams
Heavy Duty 1670 Decitex Orca
Orca (CSM) Fabric
Lifeline Around Tube
Hand Pump
Maintenance Kit
Owner´s Manual
Customized Aluminum Consoles & Seats
Fiberglass or Aluminum Jockey Consoles
Aluminum Jockey Seats
Bow Rider Seats
Sunbrella Fabric Boat Cover
Lifting Harness
Electronics Upon Request
T-Top
Stern Towing Post
Light Arch
Engine Guard
Color Boat Customization
