Large Square Transom Alum. Reinforced Base
Non-skid (CSM) Fabric on Tube
More Payload Capacity
More Internal Area
OPTIONAL PORTABLE 6 GAL FUEL TANK INSTALLED WITH FITTINGS IN BOW LOCKER
Optional Bow Locker/Seat with Vent & Storage with Capacity to Fit a 6 Gal Portable Fuel Tank
Pressure Relief Valves
Ultra High Quality Welding
Reinforced Aluminum Bow Eye w/ SS Rings
Double Solid Rubrail
Heavy Duty Keel Protector
Shallow Water Version Hull
1670 D-Tex ORCA (CSM) Coated Fabric
Sunbrella Fabric Boat Cover Available
Reinforced Alum. Lifting Eyes with SS Rings
Internal Aluminum Plate with Security Lip
Reinforced (CSM) Fabric Handles
Non-skid Rubber Floor
Reinforced Alum. Towing Eyes & Tie Downs w/ SS Rings
Custom Colors Upon Request
Overall Length
16’ / 4.88m
Overall Beam
7’ / 2.14m
Inside Length
12’8’’ / 3.85m
Number of Chambers
5
Inside Beam
3’6’’ / 1.08m
Tube Diameter
21’’ / 0.53m
Person Capacity
10
Weight
480 lbs / 218 kg
Weight with Bow Locker
501 lbs / 227 kg
Recommended HP
50hp / 37kw
Maximum HP
60hp / 44.8kw
Shaft length
20’’ / 50.8cm
RDC Design Category
C
Deadrise
6°
Aluminum Hull Thickness
0.190 in / 4.78 mm
AluminumTransomThickness
Marine Grade Aluminum Hulls
Bow Eye
Drain Scuppers
Solid Double Rub Rail
Tow Rings
3-4 Aluminum Davit Lifting Points
Non-Skid ORCA (CSM) Coated Fabric On Top of Tube
SEADECK® EVA FOAM NON-SKID FLOOR
4 Layers Reinforced Seams
Heavy Duty 1670 Decitex
Orca (CSM) Fabric
Lifeline Around Tube
Hand Pump
Maintenance Kit
Owner´s Manual
Bow Locker/Seat with Vent & Storage with Capacity to Fit a 6 Gal Portable Fuel Tank
Portable 6 gal Fuel Tank Installed With Fittings in Bow Locker
Aluminum or Fiberglass Console With Plexiglass Windshield & Grab Rail
Fiberglass or Aluminum Jockey Consoles
Customized Aluminum Console and Seats
Aluminum Jockey Seat
Leaning Bolster
Mechanica Steering System
Hydraulic Steering System
Standard Rigging From Factory
SS LED Navigation Light
All Around LED Anchor Light
Automatic Bilge Pump
Master Switch
Fuel/Water Separator & Canister
Sunbrella Fabric Boat Cover
Chock Set
Lifting Harness
Electronics Upon Request
Color Boat Customization
AB Catalogue
Model Brochure
Line Brochure
CAD Drawing
Chock & Davit Information
Accessories & Part Numbers
Owner's Manual
