Large Square Transom Alum. Reinforced Base
Non-skid (CSM) Fabric on Tube
More Payload Capacity
More Internal Area
OPTIONAL PORTABLE 6 GAL FUEL TANK INSTALLED WITH FITTINGS IN BOW LOCKER
Optional Bow Locker/Seat with Vent & Storage with Capacity to Fit a 6 Gal Portable Fuel Tank
Pressure Relief Valves
Ultra High Quality Welding
Reinforced Aluminum Bow Eye w/ SS Rings
Double Solid Rubrail
Heavy Duty Keel Protector
"V" Hull
1670 D-Tex ORCA (CSM) Coated Fabric
Sunbrella Fabric Boat Cover Available
Reinforced Alum. Lifting Eyes with SS Rings
Internal Aluminum Plate with Security Lip
Reinforced (CSM) Fabric Handles
Custom Colors Upon Request
Non-skid Rubber Floor
Reinforced Alum. Towing Eyes & Tie Downs w/ SS Rings
Optional Integrated Aluminum Fuel Tank
Overall Length
15’ / 4.57m
Overall Beam
6’9’’ / 2.06m
Inside Length
11’8’’ / 3.55m
Number of Chambers
5
Inside Beam
3’4’’ / 1.03m
Tube Diameter
19’’ / 0.48m
Person Capacity
9
Weight
392lbs / 178kg
Weight with Bow Locker
421lbs / 191kg
Recommended HP
50hp / 37kw
Maximum HP
60hp / 44.8kw
Shaft length
20’’ / 50.8cm
RDC Design Category
C
Deadrise
18°
Aluminum Hull Thickness
0.190 in / 4.78mm
Aluminum Transom Thickness
Marine Grade Aluminum Hulls
Bow Eye
Drain Scuppers
Solid Double Rub Rail
Tow Rings
3-4 Aluminum Davit Lifting Points
Non-Skid (CSM) Coated Fabric On Top of Tube
SEADEK® EVA FOAM NON-SKID FLOOR
4 Layers Reinforced Seams
Heavy Duty 1670 DECITEX
Orca (CSM) Fabric
Lifeline Around Tube
Hand Pump
Maintenance Kit
Owner´s Manual
Bow Locker/Seat with Vent & Storage to Fit a 6 Gal Portable Fuel Tank
Portable 6 gal Fuel Tank Installed With Fittings in Bow Locker
Integrated Aluminum Fuel Tank
Aluminum or Fiberglass Console with Plexiglass Windshield & Grab Rail
Fiberglass or Aluminum Jockey Consoles
Customized Aluminum Consoles & Seats
Aluminum Jockey Seat
Leaning Bolster
Mechanical Steering System
Hydraulic Steering System
Standard Rigging From Factory
SS LED Navigation Light
All Around LED Anchor Light
Automatic Bilge Pump
Master Switch
Fuel/Water Separator & Canister
Sunbrella Fabric Boat Cover
Chock Set
Lifting Harness
Electronics Upon Request
Color Boat Customization
